Self-adhesive PVC Foam Sheet
Specifications:
Foam material: vinyl
Foam density: 100 +/- 20 kg/CBM to 500 +/- 50 kg/CBM
Color: white, black, grey, brown or customized
Thickness: 0.2 mm to 20 mm
Width: max 2050 mm
Length: according to customers need
Foam adhesive: acrylic glue
Adhesive layer: single side or double side
Product Details
Self-adhesive PVC Foam Sheet is a versatile, high-performance closed-cell vinyl foam tape and sheet material engineered for sealing, cushioning, and vibration dampening. Backed with high-performance acrylic adhesive on either a single or double side, it provides instant, reliable bonding across various substrates.
Available in a broad density range from 100 to 500 kg/CBM, thicknesses from 0.2 mm to 20 mm, and customizable widths up to 2050 mm, this foam sheet can be precisely tailored to meet the exact demands of your industrial, commercial, or consumer projects.
Key Features & Advantages
Superior Sealing Performance: The closed-cell structure effectively blocks out air, dust, moisture, and water when compressed, making it an exceptional weather-stripping and anti-leakage barrier.
Strong Acrylic Adhesive Backing: Coated with premium acrylic glue, it offers excellent initial tack, long-term aging resistance, and secure bonding to metal, glass, wood, plastic, and painted surfaces.
Vibration & Shock Absorption: Excellent resilience helps absorb impacts, reduce mechanical noise, and prevent loosening caused by vibrations in dynamic environments.
Flexible Density Options: Ranging from soft low-density options ($100$ kg/CBM) for tight cushioning to high-density variants ($500$ kg/CBM) for heavy-duty structural support.
Chemical & Weather Resistance: Resistant to mild acids, alkalis, UV light, and general atmospheric conditions, ensuring long-lasting outdoor and indoor durability.
Highly Customizable: Easily die-cut, sliced, or slit into rolls, pads, or complex shapes to fit specific design blueprints.
Common Applications
HVAC & Appliance Industry: Thermal insulation, anti-condensation cushioning, and airtight sealing for air conditioners, refrigerators, and ventilation ducts.
Automotive Sector: Anti-rattle pads, dashboard gasketing, door seals, wire harness wrapping, and body panel vibration damping.
Construction & Building: Window and door weather-stripping, glass glazing seals, wall panel mounting, and expansion joint fillers.
Electronics & Electronics Housing: Dust-proof gaskets, shock-absorbing pads for screens, and spacing layers for enclosures.
General Industrial: Packaging buffers, nameplate mounting, craft applications, and anti-slip protective pads.
